Old 12-09-06, 03:13PM   #1
INJUNTOM

Posts: n/a
Default Engine pics & details thread - post 'em

Give us some details, and pics....also dyno and quarter mile results if you have them.

Let's see what you have.
  Reply With Quote
Old 12-09-06, 08:32PM   #2
Scott M

Posts: n/a
Thumbs up Re: Engine pics & details thread - post 'em

Here's the best I have:
  Reply With Quote
Old 12-09-06, 11:54PM   #3
Strelka Built
Valve Cover Expert

Strelka Built's Avatar

Join Date: Mar 2005
Location: Fort Fairfield, Maine
Posts: 317
Default Re: Engine pics & details thread - post 'em

You did an outstanding job re-creating that original patina.
__________________
Mark Strelka 1-866-446-4126 Download Brochure
www.strelkabuilt.com mark@strelkabuilt.com
Strelka Built is offline   Reply With Quote
Old 12-11-06, 12:42AM   #4
Zippy
The Unbanable

Zippy's Avatar

Join Date: Nov 2006
Location: Forest grove BC
Posts: 438
Default Re: Engine pics & details thread - post 'em

Mine. I'll be re-powdercoating it this spring. Pontiac Metalic Blue.
http://banditpowdercoat.com/Powderga...take%20003.jpg
Hopefully, a Glass shaker hood and a shaker scoop is in my future too
__________________
If it ain't broke, modify something til it is...
Zippy is offline   Reply With Quote
Old 12-22-06, 12:44PM   #5
Scott M

Posts: n/a
Lightbulb Re: Engine pics & details thread - post 'em

Quote:
Originally Posted by zedo View Post
nice alternator- did you get that from PY or Ames?
No. I got it from some negro up in Drums, PA. He had a roachy-looking Firebird with V heads on it.

Actually, I got that alternator from a '72 Cadillac in a junkyard back in '92. I think it cost me $4.

  Reply With Quote
Old 12-25-06, 11:41PM   #6
Pontiac462
Bill Bolin

Pontiac462's Avatar

Join Date: Mar 2005
Location: Shady Side Md
Posts: 518
Default Re: Engine pics & details thread - post 'em

My 474ci Pontiac.
__________________
Bill Bolin
Maryland
Ex-owner of the double blown 70 Pro Street GTO Judge

Now back to my racing roots with my "Lemanster"
Pontiac462 is offline   Reply With Quote
Old 01-03-07, 06:39AM   #7
INJUNTOM

Posts: n/a
Default Re: Engine pics & details thread - post 'em

The engine in my '64 LeMans:

-'74 455 BLOCK BORED ON POWERHONE WITH TORQUE PLATE
-BLOCK SQUARE DECKED TO PUT PISTON .005" OUT OF BLOCK
-'71 #96 D-PORT HEADS PORTED TO FLOW 240cfm@ .500 - .550" lift & 28"
-FERREA STAINLESS 2.11/1.77 VALVES APPROX .100" LONGER THAN STOCK
-ALL INTAKE RUNNERS FLOW WITHIN 5 CFM OF EACH OTHER, WITH AN AVERAGE OF 240CFM
-ALL INTAKE RUNNERS BETWEEN 165 - 170 CC
-EXHAUST RUNNERS FLOW 70% OF INTAKE
-VALVES UNSHROUDED, AND CHAMBER CC EQUALIZED
-THE CAM IS A SOLID ROLLER CUSTOM GRIND FROM COMP CAMS,GROUND FOR THIS CAR COMBINATION. LIFT IS .565/.552 WITH 236/243 @.050
-CAM IS DEGREED IN AT 4 DEGREES ADVANCED
-SIMS ROLLER CAM THRUST BEARING CONVERSION ON A ROLLMASTER TIMING SET.
-THE CONVERTER IS A 9" ATI BUILT FOR THIS COMBO ALSO.
-ATI DAMPER.
-IT USES AN EAGLE 4.21" STROKE CRANK TURNED DOWN TO 2.2" ON THE ROD JOURNALS WITH A FILLET RADIUS, AND CHAMFERED 77 BEARINGS
-BILLET STEEL RODS FOR FLOATING PINS...ARP 2000 SERIES BOLTS
-SRP FLAT TOP PISTONS WITH JE PINS/DOUBLE SPIRAL LOCKS
-RINGS ARE TOTAL SEAL CLASSIC GAPPED TO SAE SPECS FOR THE BORE SIZE, WHICH IS 4.185"
-MILODON HEAD STUDS
-ARP MAIN STUDS
-SPEED PRO OIL PUMP.
-MOROSO EXTRA DEEP PAN
-MODIFIED FULL LENGTH WINDAGE TRAY.
-MOROSO 3 QUART ACCUMULATOR
-THE PUSHRODS ARE CUSTOM LENGTH FROM COMP CAMS
-GUIDE PLATES, STUDS, AND SPRINGS ARE COMP CAMS.
-THE ROCKER ARMS ARE CROWER 1.5 STAINLESS ROLLER
-IT USES COMP CAMS 10 DEGREE RETAINERS, & LOCKS WITH LASH CAPS
-THE STUD GIRDLES, & VALLEY PAN ARE FROM KAUFFMAN RACING EQUIPMENT
-WARRIOR INTAKE MANIFOLD.
-CURRENT CARB IS AN 850 DEMON
-2" 4 HOLE SPACER.
-HOLLEY BLUE PUMP.
-1/2" FUEL LINE ALL THE WAY INTO THE TANK
-HOLLEY PRO SERIES REGULATOR WITH .437" ORIFACE
-HEADERS ARE HOOKER SUPER COMPETITION
-3" FLOWMASTER EXHAUST.
-DISTRIBUTOR IS A MALLORY COMP 9000 THAT WAS SENT OFF TO BE CONVERTED TO MAGNETIC PICKUP, AND RE-CURVED FOR 35 DEGREES AT 2000 RPM @ 12 DEGREES INITIAL.
-MSD 6AL BOX & MSD WIRES
-MSD BLASTER 3 COIL
-3.70 FORD 9" WITH CURRIE HOUSING AND AXLES.
-LAKEWOOD REAR LIFT BARS.
-COMPETITION ENGINEERING 90/10 FRONT SHOCKS
-'69 - '72 FRONT DISC BRAKES
-CURRIE EXPLORER REAR DISC BRAKES.
-REAR AIR BAGS AND ONBOARD COMPRESSOR BY AIRLIFT.
-OPTIMA BATTERY IN TRUNK




  Reply With Quote
Old 01-03-07, 10:05AM   #8
Rons67
Registered User

Join Date: Dec 2006
Posts: 428
Default Re: Engine pics & details thread - post 'em

I run a 505 IA2 with Eagle crankshaft, Eagle bushed rods, Ross pistons, Comp Cams solid roller, Edelbrock 72cc heads prepped by butler performance, Victir intake, and 1050 Dominator. Best et. was 9.69 @ 137 & 60' was 1.30
Rons67 is offline   Reply With Quote
Old 01-03-07, 06:23PM   #9
MrPushrod
Registered User

Join Date: Feb 2006
Location: Reno Nevada
Posts: 191
Default Re: Engine pics & details thread - post 'em

Quote:
Originally Posted by Pontiac462 View Post
My 474ci Pontiac.
Looks like you need a ladder to change jets.
MrPushrod is offline   Reply With Quote
Old 01-03-07, 06:42PM   #10
Gach

Posts: n/a
Default Re: Engine pics & details thread - post 'em

Actually he has the chick who was sitting on top of the blower change them
she snatches them out
  Reply With Quote
Old 01-03-07, 07:04PM   #11
MrPushrod
Registered User

Join Date: Feb 2006
Location: Reno Nevada
Posts: 191
Default Re: Engine pics & details thread - post 'em

Quote:
Originally Posted by Gach View Post
Actually he has the chick who was sitting on top of the blower change them
she snatches them out
Why didn't I think of that!

MrPushrod is offline   Reply With Quote
Old 01-06-07, 02:00AM   #12
Batman
Registered User

Batman's Avatar

Join Date: Apr 2006
Location: Sacramento, CA
Posts: 47
Default Re: Engine pics & details thread - post 'em

hmmmm, so that's how Pontiac462 gets the bug catcher so shiny.......


my GP 428 at the moment :mad: . Blown head gasket between 1-3 and 3-5, but it sure is clean inside. Man it would still roast those puny 14's with only 5 good jugs firing!

Batman is offline   Reply With Quote
Old 01-06-07, 03:13AM   #13
pack69gto
Pontiac Nut

Join Date: Jan 2007
Location: leduc alberta
Posts: 275
Default Re: Engine pics & details thread - post 'em

After looking at these photos i will have to get to work under my hood before i post pic of my motor,maybe i could get that chick to lay on the hood.Then nobody would be looking for a motor.lol
pack69gto is offline   Reply With Quote
Old 01-08-07, 05:04PM   #14
blue69bird
For Sale!! $16,500

blue69bird's Avatar

Join Date: Mar 2005
Location: Kaukauna, WI
Posts: 386
Default Re: Engine pics & details thread - post 'em

heres my little 350
__________________


Pontiac Power forever!
blue69bird is offline   Reply With Quote
Old 01-08-07, 05:28PM   #15
JKrull66
Slow 63

JKrull66's Avatar

Join Date: Jan 2007
Location: Midland, Texas
Posts: 44
Default Re: Engine pics & details thread - post 'em

Here the 462 in the 63
70 455 3 center billit caps Hard block & Oringed
Eagle crank 4.21 Stroke
Butler 72 cc E heads 315 @ .630
274 280 @ .050 Comp cam 1.5 rockers & girdle, Lifter Restricters
Victor W/ 1050 Dom. 1 inch clover spacer & Turtle
6.625 Howard Alum rods w Ross Pistons +030
Canton pan
Nunzi 1 7/8 headers
MSD Billit locked @ 36

Best so far 1.54 60' 6.54 @ 106 Not real good air 2200 - 2700 Equiv. 3440 race weight

John Krull :rolleyes:
__________________
Beers Bikes Babes and Pontiacs Rule!!!

63 Lemans 66 GTO's 05 Triumph Rocket III
http://www.facebook.com/profile.php?...was=1649586222
JKrull66 is offline   Reply With Quote
